For use with the Epilog Zing Laser Engraver.
- Noise Level less than 55dBa
- Low cost replacement filters
- Stylish colour match with Zing
- On Board compressor versions
- Comes complete with extraction hose kit
- Reverse flow filter technology

The Advantage Base Z has been designed specifically for the new Epilog Zing laser engraver. The dimensions of the unit allow the Zing to fit perfectly onto the extractor, effectively doubling it up as a work station. The distinctive blue finish has been matched with the blue ends of the laser to give a stylish installation. The unit is also offered with an onboard air compressor to provide the laser its air assist requirements. All units come complete with extraction hose kit and compressor link up on compressor models.

Back...

Part Numbers

Model

VOC Monitoring

Compressor

AD Base Z

230V

L1542A

A2003

A2007

115V

L1541A

Other Hose Kits are available. All of the above units are fitted with our standard filter combinations.
For specific applications please call us for details.

Replacement Filters and Accessories *

Model

Pre Filter

Combined Filter

AD Base Z

A1030045

A1030050

* Other Filters are available. Please call us for details.

Technical Data

Model

AD Base Z

EC

US

Dimensions (h × w × d)

770 × 760 × 560mm

30.3 × 29.9 × 22"

Weight

65kg

143lbs

Cabinet Construction

Powder coated mild steel

Powder coated mild steel

Blower

200m³/hr

117cfm

Electronics

230v 50/60Hz
Full load current: 3.7 amps

115v 50/60Hz
Full load current: 1.2 amps

Filter Specification

Model

Pre Filter

Combined Filter

Filter Media

Glass Fibre

Glass Fibre, Activated Carbon 9kg

Surface Media

12m²

2m²

Conctruction

2 Stage Maxi Pleat

Metal Case

Housing

MDPE Moulding

Mild Streel

Efficiency

EU8 (95% @ 0.8 micon)

H13 (99.997% @ 0.3 micon) Multiple Gas
